GFSH Series
The GFSH series of mixed density power connectors are ideal for those applications that require good blind mating in a small package. Multiple contact sizes facilitate the mixing of AC/DC input, signal and DC distributed output in a single package.
Loading...
Your Part Number
Total length:
0mm
Image shown is face view of male connector
General |
|
|---|---|
| Part Number Prefix | GFSH |
| Performance Level | Industrial |
| Qualifications | UL #49351 |
| RoHS Compliance | Optional |
Materials |
|
|---|---|
| Insulator Material | Nylon |
| Insulator Color | Orange |
| Flammability Rating | UL 94V-0 |
| Contact Plating | Gold flash |
Electrical |
|
|---|---|
| Insulator Resistance (GΩ) | 5.0 |
| Proof Voltage (V rms) | Up to 1500 |
| Working Voltage (V rms) | Up to 500 |
| Initial Contact Resistance (mΩ, max) | 1.6 |
| Contact Current Rating (A) | 20 |
| Contact Current Rating at 30ºC Temperature Rise | Up to 32 |
Mechanical |
|
|---|---|
| Shape | Rectangular |
| Body Style | Free cable, Panel mount |
| Insulator Construction | One-piece |
| Polarization Method | Insulator keyway |
| Locking System | Optional |
| Blind Mating | Yes |
| Contact Style | Fixed, Removable |
| Contact Size | #22, #20, #16, #12 |
| Female Contact Design | Open entry, Closed entry |
| Contact Retention Mechanism | Metal clip, Press-in |
| Contact Retention (N) | 27 to 45 |
| Contact Termination | Wire, PCB |
| Mating Cycles | 500 |
Environmental |
|
|---|---|
| Temperature Range (ºC) | -55 to 105 |
-
