The M24308 connector is a particular type of military connector standard, sometimes termed MIL-DTL-24308 and formerly known as MIL-C-24308 and MIL-PRF-24308. This connector incorporates very specific requirements and is a United States military standard of D-subminiature connectors (also known as D-subs). Small enough to fit into tight spaces and reliable enough to live a long life, M24308 connectors are an ideal choice for important but difficult tasks.
M24308 connectors are a United States military standard of D-subminiature connectors. They come in many different styles and formats with a variety of options in regard to their mounting (rigid or standard), contacts (crimp, pin and socket, solder, or insulation displacement), and type (non-environmental, polarized shell, miniature, rack, and panel). They have a wide temperature range and are designed to operate between -55°C to +125°C. Compact and spatially efficient, M24308 connectors are ideal for high-density packages. You can find these connectors assisting in everything from communication and information technology to aircraft missiles and satellites.
When space and weight are especially important and the user needs to accommodate a large number of circuits in proportion to their size, the M24308 connector is a great choice. Because of its size and efficiency, it is well suited for aircrafts, missiles, and related ground support systems. M24308 connectors are often used for applications such as military equipment, ground support devices, computer peripheral equipment, modems, information systems, communication systems, industrial instrumentation and space flight equipment. With the use of accessories and cable clamps, these connectors (which are designed primarily for use in rack and panel applications) can be adapted for other cabling requirements. All M2308 connectors boast solid, machined contacts and options include non-magnetic properties, a standard or high-density layout, non-outgassing, among others.
M24308 connectors are divided into the following classes:
- Classes G and N connectors are intended for use in applications where the operating temperature range is -55°C to +125°C
- Class N connectors are intended for use in applications where the presence of residual magnetism must be kept at low levels
- Class H receptacles are intended for use when the atmospheric pressures must be contained across the wall or panels on which the connectors are mounted
- Class D, K, and M connectors intended for use in high reliability space applications
Positronic D-sub connector families have various performance levels for the best cost to performance ratio, including the military and space performance to M24308 described here. Positronic D-sub connectors feature a wide variety of termination styles, contact variants, package sizes and creative accessories. Addressing all your expectations and concerns, Positronic gives you a great array of options so that you can find the perfect solution to your application requirement.
